EMC Hand Controls

Electronic Mobility Controls (EMC) provides hand controls for people with disabilities, allowing them to operate motor vehicles safely. Their products are designed to be easy to use and installed quickly with minimal disruption to the vehicle. They offer a wide range of products, from basic hand controls to more advanced systems with features such as power steering, power windows, and cruise control. With their products and services, EMC strives to provide independence and freedom to those with mobility impairments.

J-Series | Gas, Brake & Steering

That utilizes a multi-axis joystick input device. Motion in the X-axis is for Steering and the Y-axis motion is for Gas & Brake. The exposed height of the joystick is approximately 4.25″ and an angular displacement, or range, of only 50 degrees is required to move the input from the full left steer position to full right steer or from the full gas position to full brake. As with all AEVIT® Gas & Brake systems, the Gas & Brake input direction can be programmed by your Dealer to be either gas forward or brake forward.

WL-Series | Gas, Brake & Steering

The WL-Series is a Gas, Brake & Steering system that utilizes the same wheel input device as the W-Series for Steering and the same lever input device as the L-Series for Gas & Brake. These input devices are designed to be mounted on each side/w-series/ of the driver. However, they are interchangeable so that the system can be tailored for right or left hand steering.

XL-Series | Gas, Brake & Steering

The XL-Series is a Gas, Brake & Steering system that utilizes two separate control inputs. A joystick constrained to the X-axis (same as the X-Series) is used as the Steering input and a lever input device (same as the L-Series) is used for operation of the Gas & Brake.

XY-Series | Gas, Brake & Steering

The XY-Series is a Gas, Brake & Steering system that utilizes two separate control inputs. A joystick input device constrained to motion in the X-axis is used for Steering (same as the X-Series) and a separate joystick input device constrained to motion in the Y-axis is for Gas & Brake (same as the Y-Series). This system is well suited for persons requiring joystick control but able to utilize dual input devices.

WY-Series | Gas, Brake & Steering

The WY-Series is a Gas, Brake & Steering system that utilizes two separate control inputs. A wheel input device is provided for Steering (same as the W-Series) and a Y-axis joystick for Gas & Brake (same as the Y-Series). This system is well suited for persons requiring extremely low-effort Gas & Brake control and a miniature low-effort steering wheel.

L-Series | Gas/Brake Only

The AEVIT 2.0® L-Series is a Gas & Brake only system that utilizes a lever input device. The exposed lever height is 2.5″ and the device requires a maximum input force that can be adjusted from approximately 2.4 – 5.0 lbs. The total angular displacement, or range, of the lever from the full gas position to full brake is 90 degrees. Two (2) horizontally opposed internal dampeners provide the return-to-center mechanism and produce a smooth feel that can be adjusted independently for both the Gas and Brake direction.

Y-Series | Gas/Brake Only

The Y-Series is a Gas & Brake only system that utilizes a single axis joystick input device. The joystick is constrained to motion only in the Y-axis, thus the nomenclature Y. The exposed height of the joystick is approximately 4.25” and an angular displacement, or range, of only 50 degrees is required to move the input from the full gas position to full brake. The mechanism is extremely low-effort, requiring a maximum input force of only 0.2 lbs, and is internally spring loaded to return to the center, or null, position.

W-Series | Steering Only

The W-Series is a Steering only system that utilizes a miniature 5″ diameter wheel input device, and is the favorite amongst 2-handed drivers for ease of use. The total number of rotations from full left steer to full right steer is 5-6.7 turns depending upon the vehicle. This equates to an approximate 2:1 ratio between the W-Series input device and the OEM steering wheel. The input force required to turn the wheel is approx. 0.2 lbs. as measured at the proper orthotic position of 3.4″ from center.

X-Series | Steering Only

Is a Steering only system that utilizes a single axis joystick input device. The exposed height of the joystick is approximately 4.25” and an angular displacement, or range, of only 50 degrees is required to move the input from the full left steer position to full right. The mechanism is extremely low-effort, requiring a maximum input force of only 0.2 lbs, and is internally spring-loaded to return to the center, or null, position. The joystick is coupled internally to 3-independent and redundant electronic devices for unsurpassed safety and reliability.
